The tractor can be completed a number of fixed operations, such as irrigation, power generation, threshing, agricultural and sideline products processing, transportation, and ditching, digging, loading, road maintenance, forest management and other work, is the ideal model to realize the paddy fields, hills, mountains and pastoral areas, vegetables, orchards and other agricultural mechanization.
| Chinese 4WD Tractor | |||
| Tractor model | / | 454 | |
| Type | / | 4WD tractor | |
| Usage | / | General use | |
| Overall dimensions (Length*Width*Height) | mm | 3400×1370×2225 | |
| Wheel base | mm | 1860 | |
| Wheel tread | mm | 1040/1065 | |
| Adjust mode | / | Adjustable/Non-adjustable(Flip wheel disk) | |
| Min. ground clearance | mm | 320 | |
| Min. operation mass | kg | 1540 | |
| Standard ballast (F/B) | kg | 54/56 | |
| Max. ballast (F/B) | kg | 60/132 | |
| Number of gear | Forward/Backward/Crawl | / | 10/2 |
| Number of main gear | / | 8/2/0 | |
| Main gear/Sub gear/Others | / | (4+1)/2/0 | |
| Theoretical speed of each gear | km/h | Ⅰ：2.53；Ⅱ：3.68；Ⅲ：4.78；Ⅳ：7.82； Ⅴ：10.2；Ⅵ：15.9；Ⅶ：21.8；Ⅷ：33.6；RI:3.80；RⅡ:7.50 | |
| Connection mode of engine and clutch | / | Directly-connected | |
| Starting type | / | Electric start | |
| Power takeoff shaft power | kw | ≥28.1 | |
| Max. traction force | kn | 8 | |
